Price: 88 000 zł
* net prices
Specifications
Engine details
| Model | Xichai 4DX22-96 |
| Engine type | In-line arrangement, water-cooled four cylinder engine |
| Rated power | 70KW |
| Rated speed | 2800r/min(rpm) |
| Fuel consumption | 230g/kw.H |
Overall dimensions
| Overall length | 5710mm (bucket on ground position) |
| Overall height | Ground to Cab top 2840mm |
| Overall width | 2040mm |
| Dumping Height | 3030mm |
Operating specifications
| Steering system | Articulated frame with hydraulic power steering |
| Min. turning radius | 5460mm |
| Driving system | Hydraulic converter |
| Net weight | 5200kg |
Transmission system
| Type | Fixed-spindle power shift |
| Shift gear control oil pressure | 1,0 - 1,8 MPa |
| Rated input speed | 2500 (rpm) |
Bucket
| Bucket capacity | 0,72m3 |
| Bucket width | 2040mm |
| Bucket type | Heavy-duty bolt on teeth |
| Rated load | 2500kg |
Brake system and tyre
| Service brake | Four wheel hydraulic spread-shoed brake |
| Parking brake | Hand operated |
| Tyre | 16/70-20 |
