Price: 88 000 zł

* net prices


Engine details
ModelXichai 4DX22-96
Engine typeIn-line arrangement, water-cooled four cylinder engine
Rated power70KW
Rated speed2800r/min(rpm)
Fuel consumption230g/kw.H
Overall dimensions
Overall length5710mm (bucket on ground position)
Overall heightGround to Cab top 2840mm
Overall width2040mm
Dumping Height3030mm
Operating specifications
Steering systemArticulated frame with hydraulic power steering
Min. turning radius5460mm
Driving systemHydraulic converter
Net weight5200kg
Transmission system
TypeFixed-spindle power shift
Shift gear control oil pressure1,0 - 1,8 MPa
Rated input speed2500 (rpm)
Bucket capacity0,72m3
Bucket width2040mm
Bucket typeHeavy-duty bolt on teeth
Rated load2500kg
Brake system and tyre
Service brakeFour wheel hydraulic spread-shoed brake
Parking brakeHand operated
